| Model | GRC2132 |
| Detection | Day:2km; |
| | Night:1km |
| Consumption | 10W,808nm , NIR |
| Laser angle | 1°～20° |
| Angle and distance matching | DSS digital stepper illumination angle control, unique laser angle and distance matching technology, min 0.1°follow-up zooming |
| GHT-II super homogenizing HD illumination technology |
| 0.01°SLM optical axis aiming and locking |
| Camera | 1/2.8'' CMOS,star-class CMOS ,2 megapixel |
| | Automatic ICR switch,H.264 video format |
| Lens | 8-320mm HD lens , electrical zoom |
| Penetrate fog | Optional, optical filtering and AFR electronic enhanced image processing technology, color penetrate fog |
| GPS (optional) | Positioning accuracy | 10m |
| Time update cycle | 1ms,100ms,200ms |
| Time Accuracy | 0.001s |
| Baud rate | 4800,9600,19200,38400,57600,115200 |
| Sensitivity | detect-148dBm,tracking-165dBm |
| PT and housing | Housing | Integrated multi-window, aluminum, with wiper, waterproof seal, IP66 protection class, dustproof and waterproof |
| Internal control circuit | pan, tilt, rotate( PWM drive), the lens zoom, focus, camera DC12V power supply, laser ranging finder high and stable power supply DC24V ± 1V, color to W/B aux command, preset function, the thermostat function. |
| Load duty | 30kg |
| Angle | Pan 360 continuous, tilt + 45 ° ~ -45 °, PT azimuth display. |
| Speed | Pan 0.01～15°/S; tilt 0.01～15°/S |
| Seismic reinforcement | Super-strength stainless steel center bearings, with special damping base |
| LRF (optional) | Wave length | 1.57um |
| Detection | 50m—3km |
| | (max 15000m) |
| Ranging Accuracy | 3m |
| Repetition frequency | 10 cycles / minute |
| Power supply | DC24V |
| Interface | RS422 full duplex |
| Others | Interface | 1*RJ45 network HD visible light video, |
| | 1* DC24V, 1*RS422 |
| Ingress protection | IP66 |
| Operational temp. | -35℃～+65℃ |
| Weight | 20kg—65kg(Based on specific configuration ) |
